Monday, August 6, 2018

Servicing fails on step 6 while updating AOS

There are some hotfixes that patch modules and packages which are only available on the "onebox" sandbox (Tier 1) environments. If you happen to add these hotfixes to your VSTS Main Branch, you will most likely end up trying to install these modules and packages on your Tier 2 (ie UAT) environments, and this deployment will most likely fail. The reason is now the package has references to binaries which are not present on Tier 2.

One example is the module DemoDataSuite. From the deployment log you will find the following statement:

Running command: C:\DynamicsTools\nuget.exe install -OutputDirectory "G:\AosService\PackagesLocalDirectory\InstallationRecords" dynamicsax-demodatasuite -Source G:\DeployablePackages\GUID\AOSService\Packages

From the output, you would then find the following:

The running command stopped because the preference variable "ErrorActionPreference" or common parameter is set to Stop: Unable to resolve dependency 'dynamicsax-applicationfoundationformadaptor'.

It's true the DemoDataSuite depends on ApplicationFoundationFormAdaptor, and this Formadaptor Module is not on the Tier 2 environment.

A simple solution is to simply change the default variables for the build defintion, and make sure the DemoDataSuite is excluded from package generation.

Instructions on how to exclude named packages from the build can be found here:

If you suspect you've made custom modules and packages, and are worried they are causing your servicing to fail similarly, you may want to check the references yourself. Have a look at this post for more information on how to do that:

Friday, June 15, 2018

How do you apply the latest updates on Dynamics 365 Finance and Operations

When you deploy and environment of Dynamics 365 for Finance and Operations, you are asked to pick a version of the application along with the platform version. At the point of writing, the latest application version is 8.0 and platform version is 18. We know application version 8.0 and onwards to not allow for any overlayering of standard code. We also know that version 7.3 (the version prior to 8.0) allows overlayering.

If you choose to publish 7.3, you will get the application is it was in December 2017, and you will have to go through the process of applying a fair number of hotfixes to get your application updated.

In this post I will address this process. It is fairly well documented on docs, but I suppose it helps to read it from various sources. This post focus on the minimum effort needed to get updated. Depending on your scenario, it might be more complicated, if you for example have customizations, including extensions.

Before you leave this page, I should tell you there is a bonus part at the end of it.

This process is in two parts:
  1. Binary Updates
  2. Application Updates (or X++ Updates if you like)

Binary Updates

This part can actually be done by a non-developer. It is fairly easy to complete, and should be safe.

I start with updating a DEV environment, assuming it is aligned to the remaining environments (STAGE, PROD) when considering updates. From the environment page in LCS, I can tell there are lots of updates waiting to be installed.

I start by opening All Binary updates. Notice they are all already marked for download. You can't cherry pick these updates, you get them all. I could take only the platform updates instead, but I want everything updated, hence "All Binary updates".

When you continue, notice that you do not actually download the update, rather it is saved back to asset library.

This may take a while, as the entire thing is a couple of GB in total. Allow Asset Library analyze the package before you continue.

When the package is ready, you can go ahead and run "Maintain" and "Apply Updates" form the environment page. Pick the Binary Update package and allow for the Runbook to install it.

NOTE! This process will seed the package to your environment. Make sure you have enough space available on your Service Volume. You also want to make sure nobody is running Visual Studio on the machine while it is serviced. If your VM runs with standard disks (HDD) instead of premium storage (SSD), then the copying of files may time out. If that happens, just press the "Resume" button on the environment page. You might also notice that the machine even reboots as part of the process.

After the Binary Updates are installed, the tiles should hopefully report this.

Application Updates

The next process is a bit more technical and needs the attention of someone with a developer role.

Start by opening the Application Updates, not just the Critical Updates, but all of them. You will click "Select all" and press "Add". This will mark all of them for download.

Since I had over one thousand KBs, it took several seconds for LCS to create the download, so I simply had to wait for it to be sent to the browser for download. It is not a big file. In my example all updates were around 80MB.

The file is a, so you will have to unblock it and unzip the file to get the actual HotfixPackageBundle.axscdppck file. That is a nice and long file extension, which I can only assume means AX Source Code Deployable Package. ;-)

Tip! Did you know the file is actually a compressed file using zip? If you change the file extension to zip and unpack it, you will see all the packages and a manifest defining any dependencies between them. If you even take one of the single packages out, change the file extension to zip, you can get the details of that package. What files will be changed and how elements will be changed, and also what KB numbers are covered by that package.

Now, here comes the tricky part. While it is possible to apply this package through Visual Studio, I have found it safer to do the next part using command line util (SCDPBundleInstall.exe). Furthermore, I also ensure that there are no service or application potentially locking any files in the Package Local Directory. That means, no Visual Studio running, no IIS running and no Dynamics Ax Batch running. Have a look at the script I have shared at the end of this article.

The process is basically split in two steps:

  1. Prepare. This process analyze the content of the package and makes sure all files which will be changed in the Package Local Directory are put in source control (VSTS). That means add and edit commands, ensuring we can put them into VSTS if we mess up and need to go back to how things were before installing the updates.
  2. Install. This process analyze the content of the package and actually change files in the Package Local Directory. Any files added or removed will also be put in the list of pending changes to source control (VSTS).

You cannot run them in one single operation, you need to run Prepare first, then commit the pending changes to VSTS. Then you run it again with the Install mode to change files.

The prepare step takes less time, but it does take time. If you want to see what it is actually doing, the closest you get is having a look under your users Temp folder. It will extract the packages and the dependency manifest under C:\Users\USERNAME\AppData\Temp\SCDPBundleInstall. You will observe the tool is extracting each package, looking at the manifest of the package, and checking what files the package will change. As part of this process, it also ensures the change is added to "pending changes". When the tool is done, it removes the folder.

When prepare is complete, you will have to open Visual Studio and commit the pending changes in order to "backup" the files to source control. Give this commit a good name, so you know it is related to preparing a hotfix bundle install. Starting Visual Studio will start IIS Express, and since you will close Visual Studio when your changes are committed, you will again have to ensure IIS is stopped before you run the install step.
Remember, when Visual Studio is closed, IIS Express is normally stopped and IIS is started. This process can take a couple of seconds, so wait a few seconds before you continue with the install step.

The install step takes the longest time, but also uses the same folder to extract and analyze the packages.

Before you go ahead and commit all the updates standard modules to VSTS from DEV, you will need to make sure it builds. Your customizations may be broken, and your overlayering may have new conflicts that needs to be resolved. All of this must be handled before the application updates are put in source control (VSTS).

From there, you initiate the BUILD, take out the final artifact containing all the updated application modules (packages) and put it up in Asset Library.

When you are ready to install in STAGE, start with the Binary Updates package in Asset Library, then install the Application Update package in Asset Library.

Some potential troubleshooting hints

I did run into some issues while doing this. All of which I had to resolve manually, and some were reported back to Microsoft Support.

You might experience delays when applying the application updates due to limitations of how many transactions you are allowed to do against VSTS. These are delays, so it should only mean things takes longer.

If you get errors while running the prepare or install, it might be something wrong with one of the packages, either due to invalid manifest or dependencies. I've only seen this a few times, and it is not expected. If that happens, contact Microsoft Support.

Also be aware that if one module fails to build for whatever reason, all modules depending on that module will most likely also throw errors. So don't fall off your chair if you get a high number of compilation errors. It might just be one error, creating a chain or other errors. Solve that one error, and the other go away.


Using the SCDPBundleInstall tool is documented on docs, but for your convenience I will share a little PowerShell script that helps you run the prepare and install step. If you see any errors or improvements, I am grateful for all feedback.

function InstallHotfixBundle ([string] $file, [string]$vstsAccountName, [bool] $installMode = $false)
    $VSTSURI = 'https://{0}' -f $vstsAccountName

    # PLD is normally on C, J or K drive
    $pldPath = "\AOSService\PackagesLocalDirectory"
    $packageDirectory = "{0}:$pldPath" -f (('J','K')[$(Test-Path $("K:$pldPath"))],'C')[$(Test-Path $("C:$pldPath"))]

    $command = ('prepare','install')[$installMode]

    if ($installMode -eq $true)
        Write-Host "INSTALL MODE!" -f Yellow
        Get-Service w3svc | Stop-Service -Force
        Get-Service DynamicsAxBatch | Stop-Service -Force
        Write-Host "PREPAREMODE ONLY!" -f Yellow

    if (Test-Path -Path $file)
        Unblock-File -Path $file
        $InstallUtility = '{0}\Bin\SCDPBundleInstall.exe' -f $packageDirectory
        $params = @(
            '-{0}' -f $command
            '-packagepath={0}' -f $file
            '-metadatastorepath={0}' -f $packageDirectory
            '-tfsworkspacepath={0}' -f $packageDirectory
            '-tfsprojecturi={0}/defaultcollection' -f $VSTSURI

        & $InstallUtility $params 2>&1 | Out-String

        if ($installMode -eq $true)
            Write-Host "Hotfixes have been applied. Verify through build & sync, and commit the updates to VSTS!" -f Green
            Write-Host "Touched elements ready for backup to VSTS. Commit changes before continue with install! Remember to close Visual Studio when you are done!" -f Green
        throw 'No such file {0}' -f $file

# Remove the # to uncomment the line you want to run
#InstallHotfixBundle -file 'D:\Hotfix\HotfixPackageBundle.axscdppkg' -vstsAccountName 'YOUR_VSTS_ACCOUNT'
#InstallHotfixBundle -file 'D:\Hotfix\HotfixPackageBundle.axscdppkg' -vstsAccountName 'YOUR_VSTS_ACCOUNT' -installMode $true


Sunday, February 4, 2018

Installing a Software Deployable Package (SDP) using PowerShell

Now the PowerShell involved here is miniscule, so don't expect much. But I'm going to post this either way.

You will most likely install Software Deployable Packages using LCS, as outlined on the official docs, so why would you need a PowerShell script for this? It so happens that you need to install the package manually if you for example need to upgrade from 7.2 to 7.3 of Operations.

You download the package from LCS. After unblocking the zip-file, and extract it somewhere. I typically extract it on the Temporary Drive, the D-drive. Then you simply need to run this small script to initiate the installation locally.

#Requires -RunAsAdministrator

function InstallSDP()
    $BinaryPackageLocation = 'D:\Update'
    $Installer = $('{0}\AXUpdateInstaller.exe' -f $BinaryPackageLocation)

    if (Test-Path -Path $Installer)
        Set-Location $BinaryPackageLocation
        & $Installer 'quickinstallall' 2>&1 | Out-String
        Write-Output $("No update found in {0}" -f $BinaryPackageLocation)


Now, this will not work unless you have local admin rights. So the yes, that means if you plan to run the 7.2 to 7.3 upgrade, you need to run it on a machine where you have local admin rights. This is pointed out in question 14 on Robert Badawys FAQ on the matter.

Notice I am using the "quickinstallall" command here, and this is only applicable for OneBox Developer VMs.

So what about "devinstall"-command? You cannot use the devinstall for the upgrade package, but you can use it in other scenarios where you install customization packages and hotfixes. It was introduced in Platform Update 12, and is intended for use without the need for local admin privileges.

Friday, February 2, 2018

PowerShell script to toggle Maintenance mode

In order to change licence configurations on Operations, you need to toggle maintenance mode on or off. This can be done using a Setup tool, but on the development machines where we do not have local admin rights, the only solution would be to hack the database, like Kurt Hatlevik shows us in this blog post.

In this post I will show how you can toggle maintenance mode on or off using PowerShell. The script is intended for OneBox environments. Just paste it into a new ps1 file for future use, or run it through PowerShell ISE.

DISCLAIMER: Don't run this unless you are prepared to take the heat from restarting the entire web application. It stops and starts the web server.

function ToggleMaintenanceMode()
    $parm = @{
        ServerInstance = 'localhost'
        Database = 'AxDB'

    Get-Service "W3SVC" | Stop-Service -Force
    Invoke-Sqlcmd @parm
    Get-Service "W3SVC" | Start-Service

    $result = Invoke-Sqlcmd @parm
    [int]$value = $result.Value

    Write-Output "Configuration mode $(('disabled','enabled')[$value])"


The script shows you how you can easily run SQL commands, and even retrieve values back to your PowerShell script.


Sunday, January 28, 2018

PowerShell script for synchronizing the database

UPDATE! Just a day after posting this article, I got some valuable feedback that made me rewrite the script. I kept the top part of the post as is, for historical reference, but the new script is below. Keep reading!

In this post I want to share a neat way to use a PowerShell script for running the database synchronization when working. You probably already know you can run the database synchronization from within Visual Studio, and that is probably where most developers and consultants will do this operation, but sometimes you want the option to just run a script. Examples of this is when you copy a database between environments, or during upgrade operations.

Let's put the script out, and I'll discuss the parts below.

#Requires -RunAsAdministrator
Import-Module "$PSScriptRoot\AOSEnvironmentUtilities.psm1" -DisableNameChecking
Import-Module "$PSScriptRoot\CommonRollbackUtilities.psm1" -DisableNameChecking

function Run-DBSync()
    $SyncToolExecutable = '{0}\bin\Microsoft.Dynamics.AX.Deployment.Setup.exe' -f $(Get-AosWebSitePhysicalPath)
    $params = @(
        '-bindir',       $(Get-AOSPackageDirectory)
        '-metadatadir' , $(Get-AOSPackageDirectory)
        '-sqluser',      $(Get-DataAccessSqlUsr)
        '-sqlserver',    $(Get-DataAccessDbServer)
        '-sqldatabase',  $(Get-DataAccessDatabase)
        '-setupmode',    'sync'
        '-syncmode',     'fullall'
        '-isazuresql',   'false'
        '-sqlpwd',       $(Get-DataAccessSqlPwd)
    & $SyncToolExecutable $params 2>&1 | Out-String


Let's look at what this script does. The very first line is just a hint to the runtime that this script must be run in elevated mode. The reason is that it must get some information from the system that requires admin rights. Typically I also stop some services, like the Management Reporter Process Service, before I run the synchronization, and obviously a non-admin will struggle to do that.

Notice that I have imported some modules, and you may be wondering where I got those. These PowerShell modules are part of the Software Deployable Packages, and either you can create one yourself, or simply download one of those made available by Microsoft in LCS. Extract the package and look under the following path, \AOSService\Scripts. Just grab the two files and make sure you save them alongside your script, like the example below:

The rest is simply building the parameters for the synchronization operation, and running the tool that does the job. The output is sent to the host, so if you want to look at the result you may want to run this script in PowerShell ISE (Admin mode).

What is also neat, is that it will pick up the database credentials used for your environment, so you don't have to put those details in the script yourself.

In any case, it is a neat study in how you can organize your script in such a way that you get the code all in one visible column. It's also a stepping stone to start building your own set of scripts to maintain your development environments.

Finally, a small disclaimer: Microsoft may very well change how their PowerShell modules work in the future, so if that happens, the script above will have to change.

Updated script - no modules and works for non-admin

So here is a way to run the database synchronization without having to rely on the PowerShell modules and without having to have local admin rights. Remember this is limited to OneBox environment.

function Run-DBSync()
     # Find the correct Package Local Directory (PLD)
    $pldPath = "\AOSService\PackagesLocalDirectory"
    $packageDirectory = "{0}:$pldPath" -f ('J','K')[$(Test-Path $("K:$pldPath"))]

    $SyncToolExecutable = '{0}\bin\SyncEngine.exe' -f $packageDirectory
    $connectionString = "Data Source=localhost; " +
        "Integrated Security=True; " +
        "Initial Catalog=AxDb"

    $params = @(

    & $SyncToolExecutable $params 2>&1 | Out-String


Notice how I feed the parameters to the executable here, in comparisson to the Setup tool above. It is currently stated in the docs that you may want to use the Setup tool during upgrade scenarios.

Saturday, January 13, 2018

List hotfixes using PowerShell in D365FO (AX7)

You probably already know that you can open Visual Studio and from the "Dynamics 365" menu, under "Addins" and "Apply Hotfix", you will find a grid that lists all the hotfixes installed on your environment. The list can be copied and pasted into Excel if you need a better view and you need to filter and search the list. It works, but it could be a bit easier.

In this post I will share a neat function you can use to list installed hotfixes using PowerShell. It inspired by the post from Microsoft Support (Thomas Treen), and I got some help by some of my fellow MVPs to get inspired (shout out to Martin Draab and Lane Swenka).

The function is as follows:

function Get-HotfixList()
    # Find the correct Package Local Directory (PLD)
    $pldPath = "\AOSService\PackagesLocalDirectory"
    $packageDirectory = "{0}:$pldPath" -f ('J','K')[$(Test-Path $("K:$pldPath"))]
    [array]$Updates = @()

    # Get all updates XML
    foreach ($packagefile in Get-ChildItem $packageDirectory\*\*\AxUpdate\*.xml)
        [xml]$xml = Get-Content $packagefile
        [string]$KBs = $xml.AxUpdate.KBNumbers.string

        # One package may refer many KBs
        foreach ($KB in $KBs -split " ")
            [string]$package = $xml.AxUpdate.Name
            $moduleFolder = $packagefile.Directory.Parent

            $Updates += [PSCustomObject]@{
                Module = $moduleFolder.Parent
                Model = $moduleFolder
                KB = $KB
                Package = $package
                Folder = $moduleFolder.FullName
    return $Updates

With this function, you can list out the hotfixes to a resizable, sortable and searchable grid like this:

Get-HotfixList | Out-GridView

You can list out the hotfixes into a long string where each KB number is separated by a space. Then copy this string into LCS when searching for KBs you want to use in a Hotfix Bundle.

$list = Get-HotfixList | select KB | sort KB
$list = [string]::Join(" ", $list.KB)

Obviously you can use the function to quickly search for a specific hotfix.

Get-HotfixList | where {$_.KB -eq "4055564"}

And one final example, when installing a hotfix bundle, one of the steps are to compile the modules patched, and while you can do a full compile of all modules in the application, you could also just compile only the ones patched. To create a distinct list of modules, run the following statement.

Get-HotfixList | select module | sort module | Get-Unique -AsString

A quick note on the Package Local Directory (PLD) path. In my script I shift between K and J drive. I have only used this script on VMs in the cloud. If you need to run this where the PLD path is on some other drive, you will need to change that in the script.
